Milk Powder Vacuum Loader and Dosing System

Filquip with our partners has designed and supplied a new vacuum loader system with storage hopper and volumetric feeder system to transfer and dose milk powders in a dairy production plant.

The following Filquip equipment package was provided for this system:

  • FVC-5-NP Filquip Vacuum Loader unit (5.5kW, 65mm Suction Line Diameter).
  • 1.5m3 volume SS304 storage hopper with Vibration, Aeration and Load Cells Package.
  • WAM VLQ.0250.P3 SS304 Slide Gate Valve with CMG0250i Handwheel Actuation Kit.
  • WAM MBF042A SS304 Volumetric Dosing Microbatch Feeder with Outlet Pneumatic Closure Valve. Sized for dosing at a rate of 1.2 L/min.

Milk Powder Vacuum Conveyor

Milk Powder Vacuum Loader

Milk Powder Feeder

Grout Bagging Machine Dust Extractor

Filquip has recently Specified and Supplied a Dust Extraction System to collect dust from various pickup points across a set of Packing Machines and Additive Tip in Stations in a Grout bagging plant. Waste dust is deposited in a bulk bag for simple re-use of waste or easy disposal.

  • Dust Collector FPHTU54 (54m2 Bag Unit) with automated reverse pulse cleaning.
  • 11kw Fan Set.
  • Painted Mild Steel Hopper with RVR05.10 Rotary Valve as an airlock.

Packing Machine Dust Extractor





Free standing dust extractors

Free Standing Dust Extractors

Filquip is a Brisbane based supplier to free standing dust extractors. These units are perfect for connecting to your ducting network and providing dust extraction from a number of pick points, hoods and other locations as required across your plant.

Filquip also offers ducting sizing and design layouts to get the correct ducting diameters and routing to avoid the dust settling in the ductwork or moving too quickly through the ducting which will prematurely wear out the ducting bends.

Our free standing dust extractors are offered in a number of sizes from 60m3/hr suction airflow up to 15,000m3/hr airflow with over 50 different models across the range to cover any airflow requirement inbetween.

The dust collection device on the dust extractor hopper can be fitted as a 50L bin, Bulk Bag filler or Drum filler option.

Photo of a Dust Extractor with a 50L Bin and Seat Kit as the dust collection device:

Animal Feed Additive Powders Dust Extraction System



Photo of a Dust Extractor with a Bulk Bag Filler as the dust collection device:

Free standard dust extractor to bulk bag

Image of a Dust Extractor with a Drum Seal Filler as the dust collection device:

Free standing dust extractor to drum

Free Standing Dust Collectors

Filquip is a Brisbane based supplier to free standing dust collectors. These units are perfect for connecting to your Silos or Hoppers that are being filled by a tanker truck or other pneumatic conveying system when it is not possible to have the dust collector mounted onto the silo/hopper, or when you when it is desirable to conenct multiple silos/hoppers to the one free standing dust collector.

Filquip also offers ducting sizing and design layouts to get the correct ducting diameters and routing to avoid the dust settling in the ductwork or moving too quickly through the ducting which will prematurely wear out the ducting bends.

Our free standing dust collectors are offered in a number of sizes from 60m3/hr suction airflow up to 7,500m3/hr airflow with over 50 different models across the range to cover any airflow requirement inbetween.

The dust collection device on the dust extractor hopper can be fitted as a 50L bin, Bulk Bag filler or Drum filler option.

Photo of a Dust Collector with a 50L Bin and Seat Kit as the dust collection device:

Free standing dust collector

Mixer Tip in Station Dust Extractor

Filquip has recently supplied a FNS2J12 Dust Extractor to a customer as part of an upgrade with the tip in system to their mixer. Previously staff opened the mixer lid and split the bags on the edge of the mixer to pour the bags into the mixing chamber. This created a dust hazard when pouring the bags which Filquip was asked to advise in a Dust Control Solution.

The devised solution included along with the Dust Extractor unit itself, an upgrade to the lid of the mixer to include a hood with perspex doors allowing the new dust extractor installed above to capture the dust generated and contained within the hood. Once the doors are closed after the bags are emptied then the dust collector can reverse pulse clean the dust from the filters into the mixer, therefore no product is lost from the system.

Dust Extractor for Tip in Station

Filquip Dust Extractor for Mixer Tip in Station



Teflon coated rotary valves

Filquip recently supplied a customer handling hazardous wastes with a Special Build TOREX RV02 with Teflon coated body and rotor with SS316 Stainless Steel chambered rotor tip blades. Its a special “non-stick” rotary valve with a capacity of 1.2m3/hr operating at 10RPM speed.

Non-stick rotary valve with teflon coating     Filquip Teflon Coated Torex Rotary Valve

Rotary Valve Construction

Spodumene Dense Phase Conveying

Filquip has done a number of Dense Phase Conveying Trials for Spodumene Ore (An ore of lithium).

When the product was first received it was quite wet in the sample bucket and this did not load or convey well, getting stuck. Once laid out in drying pans and dried out in the sun for 4 hours (5.3% loss of product weight or 5.3% of the original product weight was moisture driven off) then it conveyed very well through the dense phase conveyor.

The video shows how much the wet Spodumene binds to itself in the video of loading and conveying and then how easily it flows once dried out (but more dusty to handle once dried).

Fly Ash Dense Phase Conveyor

Filquip was engaged to specify, supply and commission a Fly Ash Dense Phase Conveyor to transport 9TPH of product a distance of 40m from a Bulk Storage Silo to a Day Bin over the production line.

The system was designed to replace the older Lean Phase Conveying system which was experiencing significant wear and maintenance requirements resulting in shutdowns of the plant. The new Dense Phase Conveyor is designed for abrasive products and only has one simple moving part in the build for minimal maintenance.

The following equipment package was supplied by Filquip:

  • BARTOne 300 Dense Phase System 300L Vessel Capacity, Throughput capacity of 9,000kg/hr of Fly Ash at 40m distance.
  • Inclusive of Electrical Control and Air Control Panels and Pipeline Air Boosters for the Dense Phase System.
  • Extrac BA.1.1.1500 Bin Activator 1500mm diameter in Painted Mild Steel Build.
  • Drop Through Rotary Valve (Model RV10.20, CS, 1.1kW Motor).

View the Filquip Dense Phase Conveyor Range

Dense Phase Conveying Fly ash

Filquip Flyash Dense Phase Conveyor

Cement Loading Bellows for Isotainers

Filquip has completed the Design, Supply and Commissioning for a set of 4 Loading Bellows for existing cement silos on a mine site. The silos are used for bulk cement storage and they fill into individual isotainers which transport the cement to the underground section of the mine.

The new loading bellows provide a safe way for truck drivers to load the cement into the isotainers as the previous method was a hand operated valve and rubber sock. Drivers can now position their truck with Isotainer on the back under the bellows and use the remote pendant controller to lower the bellows outlet onto the inlet of the isotainer.

The integrated dust extractor ensures there is no dust released during the filling process.

The pneumatic actuated slide gate valve allows the operator to open the flow of product as they wish and shut if off as required along with the integrated level sensing in the loading bellows also automatically shutting off the valve and product flow when the Isotainer is full preventing overfilling and backing up into the chute.

The following specifications were included for the Loading Bellows:

  • Qty 4: BellowJet ZAMBA.25 Models with integrated Dust control extractor in the Unit
  • 0.55kW Winch Motor and 24v Reverse Pulse Automated Air Filter Cleaning System.
  • Integrated Level Indicators for Control Feedback to the Actuated Slide Gate Valve.
  • Inner and Outer Bellows system with wear resistant inner cones.
  • With anti-spillage closure cone that retracts to close the outlet after filling is completed
  • Stroke of 2260mm (4170mm extended length, 1910mm retracted length). 300mm diameter bellow.
  • 250 m3/hr Throughput Capacity.

Filquip Silo Loading Bellows for Cement

Mine site loading bellows

Quarry Stone Dust Wetting System

Filquip has recently worked with a quarry plant construction company to provide a Quarry Stone Dust Wetting System for the fines generated through the quarry screening processes.

The Filquip supplied Dustfix unit allows the plant to put the fine quarry stone dust onto a belt conveyor for stockpiling without all the excessive dust emissions generally associated with handling fine dusts on belt conveyors.

Filquip is proud to have supplied the following equipment for the Quarry Stone Dust Wetting System .

  • Dustfix Dust Conditioner (Dustfix 20 Model, 20m3/hr capacity)
  • TOREX Rotary Valve RV20.20
  • Tubular Screw Conveyor from Screen Deck Outlet to Dustfix Unit (TS.219 Model, DN200, 6000mm Long, Painted Mild Steel, SAC Screw – no hanger bearings)

Quarry Stone Dust Wetting System





Quarry Screen Deck Dust Extractor

Filquip has recently supplied a WAM FPHUT54 Dust Extractor with hopper and Chrome Bore RV05.10 Rotary Valve to control the dust generated in a quarry screen house.

The unit has been commissioned by Filquip and all parties are extremely pleased at the performance of the unit in controlling the dust emissions off the quarry screen deck.

Quarry Screen House Dust Extraction

Filquip Dust Extractor for Quarry Screen House
